General Description:
SUNPASS CNAF/PTFE gaskets for tank container applications combine the chemical inertness and hygienic qualities of 100% virgin PTFE with the mechanical properties of the compressed non asbestos fiber sheet.
Applications:
These gaskets are designed for flanged joints handling aggressive fluid media that would swiftly destory the integrity of other mateiral and for duties with foodstuffs where cleanliness and non-contamination are essential
Service Capabilities:
Tank working pressure: 4.4bar
Esaily meets tank test pressure: 6.0bar Maximum temperature: 250℃ Technical Datas:
Code Description Size
1291200000 Flat Gasket for Grav Disch Round, flat,CNAF/PTFE,Int Dia 114mm, Ext Dia 200mm, 2.5mm thick, drilling 8X14/PCD 178mm
1291310000 Flat Seal Joint Plat Dia 90x75.5 e 2.5(A)
1291420000 Flat Gasket 3" Outlet Spigot Square CNAF/PTFE gasket 144X144.4X18. Holes/PCD 160mm, Internal Diam. 90mm
12912040000 Flat Gasket with Casing PTFE Ext Dia 176mm Int Dia 82mm-4Sloted holesX18 on min PCD 145mm for flanged SRV
